Tripp Lite SMART1500LCD 1500VA 2U Rack Mount UPS 900W Battery Backup
Utility power fluctuates before it drops entirely. We built this unit to slide into a standard equipment rack or stand upright on the floor beside a desk. When the line voltage sags or spikes, it trims and boosts the feed back into range without draining the internal cells.
Price as the listing last showed it. Listings move, so the figure on the page you land on is the one that counts at checkout.
- 1500VA/900W UPS: Eight NEMA 5-15R outlets provide reliable UPS battery backup & surge protection for servers, computers, and peripherals. The six-foot NEMA 5-15P input power cord ensures easy connection to compatible AC outlets
- 2U RACK MOUNT UPS: Versatile mounting options in 2U rackmount space or vertical tower with included adapter. Ideal for small servers, network devices, desktop PCs, monitors, workstations, entertainment systems, wireless routers, and more
- AUTOMATIC VOLTAGE REGULATION: AVR corrects brownouts and overvoltages from 75V to 147V back to safe 120V without using battery power. Features Modified Sine Wave (PWM) output in battery mode and Sine Wave in AC mode for low total harmonic distortion
- ADVANCED POWER FEATURES: User-replaceable internal batteries and RJ45 Ethernet port for dataline surge protection up to 100 Mbps. The large rotatable LCD screen monitors operations like voltage, runtime, load, battery, and operating mode
- FULLY SUPPORTED: Protected by a 3-Year Limited Manufacturer's Warranty and a $250,000 Ultimate Connected Equipment insurance. To best support your purchase, Eaton's expert technical team is available via phone, web, or email to address any concerns
How this one is built
Line voltage regulation
The internal circuitry cleans up incoming utility power when the line dips low or climbs high. It corrects the voltage continuously so your connected equipment receives steady power while the battery remains on standby for an actual blackout.
Rack or tower orientation
Install the chassis into an equipment rack using the mounting brackets, or set it vertically on end as a free-standing tower. The front panel display rotates so you can read voltage and load levels clearly in either position.
Network line protection
An integrated network port passes your data cable through transient suppression before it reaches a router or switch. It helps isolate sensitive communications equipment from surges that travel along twisted-pair wiring across a building.
Internal battery maintenance
When the utility feed drops out, the inverter takes over the load immediately. The internal battery pack is easy to service, and the front display tells you how much runtime and capacity remain as the hardware operates.
On the nameplate
These are the figures published for this unit. Where a number is missing here it was not printed on the listing, and we would rather leave the row out than fill it with a guess.
| Outlets | 8 |
|---|---|
| Volt-amps | 1500 VA |
| Watts | 900 W |
| Voltage | 120 V |
| Amps | 12 A |
| Connector | HD15 |
| Material | Acrylonitrile Butadiene Styrene |
| Color | Black |
| Weight | 29 pounds |
| Warranty | Three years |
